Technicals

Ref.-No:              082.060A

Ambient Temp:              -10°C to 60°C

Resolution       0.1°C

Accuracy ±      1.5°C

Relative Humidity:              0% to 100% r.H.

Resolution       0.1% (20 to 80%)

Accuracy ±      3% / 25°C

Sound Pressure:              30 to 130dB (A):

Resolution       0.1%

Accuracy ±      1.5 dB

Sound Pressure:               30 to 130dB (C):

Resolution       0.1%

Accuracy ±      1.5 dB

Frequency range      100 to 8000 Hz

Test conditions        94dB, 1 kHz sine curve

Illuminance:               At a colour temperature of 2856 K

0 to 2 klx:               1 lux / ± (5% of measured value + 10 digits)

0 to 20 klx:               10 lux / ± (5% of measured value + 10 digits)

0 to 50 klx:               100 lux / ± (5% of measured value + 10 digits)

Wind speed:

0.5 to 20 m/s:              0.1m/s / ± (3% of measured value + 10 digits)

1.8 to 72 km/h:              0.1km/h / ± (3% of measured value + 10 digits)

1.6 to 65.7 ft/s:              0.1ft/s / ± (3% of measured value + 10 digits)

0.9 to 38.9 knots:              0.1 knots / ± (3% of measured value + 10 digits)

Airflow:

0 to 999.9 CMM m/s:              ± (3% of measured value + 10 digits)

Power Supply:              1 x 9 V IEC 6F22

Operating Temp:               0°C to 60°C

Dimensions:               280 x 89 x 50 mm

Weight:              0.430 kg
