Demo laser scanner with all accessories and factory calibration.
This demo Z+F IMAGER® 5010X laser scanner comes with all accessories and post-processing software. The Imager 5010X can estimate the current scanner position and orientation, helping to support the user registration algorithm. This laser scanner set also comes with a factory re-calibration certificate. For further information and sample datasets, please get in touch with our sales staff.
The view extra information on the 5010X laser scanner, please see the following links below.
Videos
Technicals
Drastically improved Wi-Fi speed and range
Working with the 802.11n-standard and dual antennas, the Z+F IMAGER® 5010X has an increased working range and allows you to communicate and stream scan data quickly to the Scout tablet.
Range up to 187 meters (approx. 600 ft.)
Due to the wavelength and the approved ranging system, the devices operate within a maximum range of 187 m (approx. 600 ft.).
High-speed up to 1 million pixel/second
With a maximum measurement rate of 1,016,027 pixel/sec some laser scanners of Zoller + Fröhlich are one of the fastest in the world.
320° x 360° field-of-view
The large 320°x 360° field-of-view yields maximum coverage.
Laser class 1
Most laser scanners of Zoller + Fröhlich are classified “eye-safe” according to laser class 1 requirements.
HDR i-Cam
The integrated camera works very well in all environments. One focus is to always provide realistic panoramas. To make the workflow as user friendly as possible, the Z+F i-Cam is fully integrated into the Z+F IMAGER® 5010X.
Stable
The new dynamic compensator ensures maximum reliability of your scans.
Upgrade your Scanner to X
Zoller + Fröhlich offers you to upgrade your Z+F IMAGER® 5010C to a Z+F IMAGER® 5010X.
Please contact our sales department to get more information.
